Full HD 1080p 60Hz Signal Transfer
Supports Passive 3D Transmission
Eliminates Wire Clutter Behind Your HDTV
Wireless Connection Between TV & Media
Dual HDMI Inputs & Composite RCA Input
HDMI, Composite & Component Outputs
Wireless 802.11n Wi-Fi Connectivity
Transmission Range: 131' (40 m)
Ethernet & USB Connectivity
IR Extender Included
Operation Distance |
131' (40 m) |
Frequency Range |
5.15 - 5.25 GHz |
Video Inputs |
Transmitter: HDMI x 2 Transmitter: Composite x 1 |
Video Outputs |
Receiver: HDMI x 1 Receiver: Composite x 1 Receiver: Component x 1 |
Video Resolution |
1920 x 1080p (24/30/60 fps) 1920 x 1080i (24/30/60 fps) 1280 x 720p 640 x 480p 640 x 480i |
Signal Frequency |
60 Hz |
3D Support |
Supports passive 3D transmission (for passive non-shutter glasses) |
Video Streaming |
<30 ms Latency |
Audio |
AC-3 Dolby Digital 5.1 DTS Digital Audio Analog 48 kHz 16-bit ADC |
Audio Input |
Transmitter: 3.5 mm mini jack x 1 (PC audio) |
Audio Output |
Receiver: 3.5 mm mini jack x 1 (analog stereo audio) |
USB |
Receiver: USB Type-A (female) x 1 |
LAN |
Transmitter: Ethernet (10/100 Base) x 1 Receiver: Ethernet (10/100 Base) x 1 |
PC Input Terminal |
High-density 15-pin D-Sub (RGB) x 1 |
Wireless Configuration |
OFDM: supporting IEEE 802.11n |
Antenna |
Internal Antenna (Transmitter & Receiver) x 2 MIMO Interface |
Encoding Formats |
H.264 Baseline Profile with Level 4.2 HDCP compliant |
Broadcasting Number of Locations |
1 Transmitter to 4 Receivers (extra receivers sold separately) |
Security |
802.1x 802.11i WPA2 WPA WEP 64/128 TKIP AES |
IR Port |
Transmitter: IR output x 1 Receiver: IR input x 1 |
Remote Control |
Yes |
Power Requirements |
Voltage: DC 12 V Amps: 2A Consumption: 12 V, 2A |
