RESOLUTION
1024 x 768
THROW RATIO
1.96 ~ 2.15
THROW DISTANCE
3.9 - 43 ft / 1.19 - 13.11 m
BRIGHTNESS (LUMENS)
3,800 ANSI
DISPLAY
TYPE
DLP Lamp
RESOLUTION TYPE
XGA (1024x768)
RESOLUTION
1024 x 768
BRIGHTNESS (LUMENS)
3,800 ANSI
DISPLAY SIZE (IN.)
30 - 300 in. / 0.76 - 7.62 m
THROW DISTANCE
3.9 - 43 ft / 1.19 - 13.11 m
THROW RATIO
1.96 ~ 2.15
KEYSTONE
Vertical (+/- 40°)
LENS
1.1x optical zoom
LIGHT SOURCE (WATT)
190
LIGHT SOURCE LIFE, NORMAL (HOURS)
5000
LIGHT SOURCE LIFE, DYNAMIC ECO-MODE (HOURS)
15000
COLOR DEPTH
1.07B Color (R/G/B 10bit)
DYNAMIC CONTRAST RATIO
22,000:1
ASPECT RATIO
4:3
VIDEO SIGNAL
FREQUENCY HORIZONTAL
15K~102KHz
FREQUENCY VERTICAL
23~120Hz
COMPATIBILITY
PC RESOLUTION (MAX)
VGA (640 x 480) to WUXGA_RB (1920 x 1200)
MAC® RESOLUTION (MAX)
VGA (640 x 480) to WUXGA_RB (1920 x 1200)
CONNECTOR
MINI USB TYPE B
1
AUDIO OUTPUT (MINI JACK)
1
3.5MM AUDIO IN
1
CONTROL (RS232)
1
HDMI 1.4 IN
1
VGA IN
2
VGA OUT
1
COMPOSITE RCA VIDEO IN
1
AUDIO
INTERNAL SPEAKERS
2W (x1)
POWER
VOLTAGE
AC 100-240V (universal), 50-60Hz
CONSUMPTION (TYPICAL)
260W
STAND-BY
<0.5W
OPERATING CONDITIONS
TEMPERATURE
32-104º F (0 - 40º C)
WEIGHT (IMPERIAL)
NET (LBS)
4.9
GROSS (LBS)
7.1
